1 function
centre distance: 150 ± 12 mm
maximum flow rate at 3 bar: 12 l/min
ceramic cartridge
temperature limitation adjustable
non-return valve
with silencer
hose connection DN15
connection dimension: DN15
min. operating pressure: 1 bar
max. operating pressure: 10 bar
connection type: S-connections
