2 functions
projection: 209 mm
centre distance: 150 ± 12 mm
spray type mixer: normal spray
flow rate for bath spout at 3 bar: 19 l/min
flow rate of hand shower at 3 bar: 14,7 l/min
ceramic cartridge
temperature limitation adjustable
pressure diverter Select with automatic resetting
protected against backflow, according to DIN EN 1717
with silencer
suitable for continous flow water heaters
connection dimension: DN15
connection type: S-connections
wall-mounted
min. operating pressure: 1 bar
max. operating pressure: 10 bar
