2 functions
simultaneous utilization of 2 functions
Select push-button on/off control for 2 outlets
CoolContact thermostat: Prevents the housing from heating up, making showering even safer
Start/stop valve to operate the functions, thermostat cartridge
maximum flow rate at 3 bar: 28 l/min
flow rate upper outlet: 28 l/min
min. operating pressure: 1 bar
max. operating pressure: 10 bar
control of an external shower or bath tub filler via concealed connection G ½ possible
Safety stop at 40 °C
temperature limitation adjustable
with isolated water conduction
non-return valve
with silencer
shelf made of safety glass
surface shelf: mirror glass
material handles: metal
centre distance: 150 mm
connection dimension: DN15
connection type: adjustable connection, G ½
dirt filter included
thermostat is delivered with buttons Rain large and hand shower
