1 function
comfortable turning on / off of one outlet with large Select-paddle, precise temperature control thanks to vertical handle structure and haptic feedback from the thermostat handle
water flow control with stop function
T30, AVP
maximum flow rate at 3 bar: 20,3 l/min
min. operating pressure: 1 bar
max. operating pressure: 10 bar
flat escutcheon for more space in the shower
escutcheon can be aligned by +/- 3°
easy installation due to pre-assembled function block, handles always at the same height regardless of the installation depth of the basic set
Safety stop at 40 °C
temperature limitation adjustable
the thermostat offers the possibility for thermal disinfection
material button: metal
material handles: metal
connection type: basic set iBox universal 2 (# 01500180)
thermostat is delivered with button On/Off
