1 function
temperature and water flow control
water flow control with stop function
thermostat cartridge
maximum flow rate at 1 bar: 19,5 l/min
flow rate upper outlet: 32 l/min
flow rate lower outlet: 32 l/min
flow rate by simultaneous use of all outlets: 34,8 l/min
maximum flow rate at 3 bar: 34,8 l/min
min. operating pressure: 1 bar
max. operating pressure: 10 bar
escutcheon can be aligned by +/- 3°
easy installation due to pre-assembled function block
handles always at the same height regardless of the installation depth of the basic set
Safety stop at 40 °C
temperature limitation adjustable
the thermostat offers the possibility for thermal disinfection
material handles: metal
connection type: basic set iBox universal 2 (# 01500180)
