consists of: overhead shower, wall outlet
shower head size: 250 mm
spray type: PowderRain, Intense PowderRain, RainStream
flow rate PowderRain spray at 3 bar: 9 l/min
flow rate Intense PowderRain at 3 bar: 9 l/min
flow rate RainStream spray at 3 bar: 9 l/min
function from: 8,9 l/min
maximum flow rate at 3 bar: 9 l/min
minimum flow pressure: 1,9 bar
Select button on thermostat
projection: 273 mm
middle spray disc: 151 mm
frame: metal
material spray disc: aluminium
spray disc surface: graphite
overhead shower removable for cleaning
shower head vertically inclinable by 10-30°
the 3 spray zones must be controlled via 3 valves or a diverter valve with 3 outlets
installation: wall-mounted - based on iBox
connection dimension: DN15
not suitable for continuous flow water heaters
