consists of: overhead shower, hand shower, shower thermostat, shower hose, slider, shower bar
overhead shower Raindance S240 P
shower head size overhead shower: 240 mm
spray type overhead shower: PowderRain
spray type hand shower: PowderRain, Rain, Whirl
maximum flow rate for Showerpipe at 3 bar: 8 l/min
minimum flow pressure: 1,5 bar
max. operating pressure: 10 bar
height-adjustable slider
shower arm length overhead shower: 460 mm
swivel shower arm
thermostat Ecostat Comfort
SafetyStop at 40°C
adjustable hot water limitation
outlets controlled via turning handle
suitable for continuous flow water heaters
mounting type: exposed installation
connection dimension: DN15
connection thread: G ½
centre distance: 150 ± 12 mm
pipe can be shortened in height
intrinsically safe against backflow
shower bar diameter: 25 mm
2 functions
EU taxonomy: max. 8 l/min - Do No Significant Harm (DNSH)
