consists of: overhead shower, hand shower, slider, single lever shower mixer, shower hose, shower bar
overhead shower Croma 280
shower head size overhead shower: 280 mm
spray type overhead shower: RainAir
spray type hand shower: Massage spray, IntenseRain, SoftRain
maximum flow rate for Showerpipe at 3 bar: 15 l/min
minimum flow pressure: 1 bar
max. operating pressure: 10 bar
ball-joint: overhead shower angle adjustable
pipe can be shortened in height
shower bar diameter: 22 mm
height-adjustable hand shower holder
shower arm length overhead shower: 400 mm
swivelling shower arm
suitable for continuous flow water heaters with an output of 18 kW
mounting type: exposed installation
connection dimension: DN15
connection thread: G ½
centre distance: 150 ± 12 mm
ceramic cartridge
temperature limitation adjustable
2 functions
flow rate RainAir spray at 3 bar: 15 l/min
