2 functions
simultaneous utilization of 2 functions
Select push-button on/off control for 2 outlets
Start/stop valve to operate the functions, thermostat cartridge
maximum flow rate at 3 bar: 21 l/min
flow rate for bath spout at 3 bar: 21 l/min
flow rate of hand shower at 3 bar: 13 l/min
Safety stop at 40 °C
temperature limitation adjustable
non-return valve
protected against backflow, according to DIN EN 1717
with silencer
material handles: metal
shelf made of safety glass
surface shelf: mirror glass
connection dimension: DN15
connection type: G ½
centre distance: 150 ± 12 mm
dirt filter included
thermostat is delivered with buttons hand shower and bath tub
