temperature and water flow control, precise temperature control thanks to vertical handle structure and haptic feedback from the thermostat handle
water flow control with stop function
thermostat cartridge
maximum flow rate at 1 bar: 12,8 l/min
flow rate upper outlet: 24 l/min
flow rate lower outlet: 23 l/min
flow rate by simultaneous use of all outlets: 34,8 l/min
maximum flow rate at 3 bar: 24 l/min
min. operating pressure: 1 bar
max. operating pressure: 10 bar
flat escutcheon for more space in the shower
escutcheon can be aligned by +/- 3°
easy installation due to pre-assembled function block
handles always at the same height regardless of the installation depth of the basic set
Safety stop at 40 °C
temperature limitation adjustable
material button: metal
material handles: metal
connection type: basic set iBox universal 2 (# 01400180)
