consists of: overhead shower, hand shower, shower thermostat, shower hose, slider, shower bar
shower head size overhead shower: 279 mm
spray type overhead shower: Rain, RainAir
convenient spray selection via Select button
individually height adjustable shower head with easy-to-use twist lock. Adjustment 300 mm
flow rate RainAir spray (at 3 bar): 14 l/min
flow rate Rain spray (at 3 bar): 15 l/min
spray type hand shower: Rain
flow rate of hand shower at 3 bar: 8 l/min
maximum flow rate for Showerpipe at 3 bar: 21 l/min
minimum flow pressure: 1 bar
max. operating pressure: 10 bar
ball-joint: overhead shower angle adjustable
shower bar diameter: 25 mm
height-adjustable hand shower holder
shower arm length overhead shower: 470 mm
swivel shower arm
safety stop at 40°C
adjustable hot water limitation
outlets controlled via turning handle
suitable for continuous flow water heaters
mounting type: exposed installation
connection dimension DN15
connection thread G ½
centre distance 150 ± 12 mm
intrinsically safe against backflow
2 functions
