3 functions and 1 additional outlet
simultaneous use of several outlets
comfortable turning on / off of outlets with large Select-paddle
Eco-Function: flow rate regulation via lever handle, depending on volume flow and installation situation approx. 50% flow rate reduction
T30, AVP
maximum flow rate at 3 bar: 30 l/min
flow rate per outlet: 24 l/min
flow rate by simultaneous use of all outlets: 30 l/min
min. operating pressure: 1 bar
max. operating pressure: 5 bar
Safety stop at 40 °C
temperature limitation adjustable
the thermostat offers the possibility for thermal disinfection
non-return valve
connection type: basic set
Thermostat is delivered with buttons handshower, Rain large and Body spray
