consists of: 2-handle bath mixer, hand shower, shower hose, shower holder
2 functions
projection: 224 mm
centre distance: 170 ± 32 mm
spray type mixer: normal spray
spray type hand shower: RainAir
maximum flow rate at 3 bar: 20 l/min
flow rate for bath spout at 3 bar: 20 l/min
flow rate of hand shower at 3 bar: 14 l/min
ceramic valves hot/cold 90°
non-return valve
suitable for continous flow water heaters
connection dimension: DN15
connection type: s-shaped connections
wall-mounted
min. operating pressure: 1 bar
max. operating pressure: 10 bar
