consists of: 3-hole rim mounted single lever bath mixer, baton hand shower, shower holder
2 functions
projection: 155 mm
spray type mixer: normal spray
maximum pull-out length of hand shower: 1,45 m
sBox for quiet, smooth and protected hose guidance
maximum flow rate at 3 bar: 20 l/min
flow rate for bath spout at 3 bar: 20 l/min
flow rate of hand shower at 3 bar: 10,6 l/min
ceramic cartridge
temperature limitation adjustable
non-return valve
suitable for continous flow water heaters
connection dimension: DN15
connection type: basic set
installation on bath rim
min. operating pressure: 1 bar
max. operating pressure: 10 bar
removable for service at any time
no additional maintenance opening required
spray type hand shower: Rain, MonoRain
