Features
Connection
Internal thread
Diverter
Turn operated diverter
Concealed parts
Gasket sleeve for dry mortarless construction, Mounting box and cover sleeve, Multifix fastening system
Mechanical parts
Thermostatic cartridge for automatic temperature control
Advanced features
Inner body made of DZR brass
Flow attributes
Flow-rate at 3 bar
20.4 / 20.4 l/min
Technical properties
Connection size
G1/2
Hot water supply
max. +80°C
Material
Brass
Working pressure
0.5 - 10 bar
Regulations
EN standard
EN 817
