Features
Concealed parts
Square rosette, Fastening of the function unit with screws
Mechanical parts
ø 35 mm ceramic cartridge for flow and temperature control
Color
Chrome
Temperature
Limitation option for maximum temperature and flow-rate, Adjustable hot water stop (included, retrofittable)
Flow attributes
Flow-rate at 3 bar
22.2 l/min
Technical properties
Hot water supply
max. +80°C
Working pressure
0.5 - 10 bar
Regulations
EN standard
EN 817
