Features
Lever/Handle
Single operating lever/handle, Hot/Cold symbols
Mechanical parts
ø 40 mm ceramic cartridge for flow and temperature control
Color
Chrome
Temperature
Limitation option for maximum temperature and flow-rate, Adjustable hot water stop (included, retrofittable)
Technical properties
DN-size (nominal dimension)
DN15
Hot water supply
max. +80°C
Installation width
45 mm
Working pressure
0.5 - 10 bar
Regulations
EN standard
EN 817
Sustainability
EPD module A1 (kg CO2 eq.)
5,54
EPD module A1-A3 (kg CO2 eq.)
6,43
EPD module A2 (kg CO2 eq.)
0,26
EPD module A3 (kg CO2 eq.)
0,64
EPD module A4 (kg CO2 eq.)
0,23
EPD module C2 (kg CO2 eq.)
0,01
EPD module C3 (kg CO2 eq.)
0,01
EPD module C4 (kg CO2 eq.)
0,46
EPD module D (kg CO2 eq.)
-4,08
