Features
Additional features
protected against back-flow in domestic use (according to DIN EN 1717)
Connection
Flexible inlet pipes
Diverter
Turn operated diverter
Concealed parts
ROLLBOX with automatic hose wind
Mechanical parts
ø 40 mm ceramic cartridge for flow and temperature control
Temperature
Limitation option for maximum temperature and flow-rate, Adjustable hot water stop (included, retrofittable)
Technical properties
Backflow prevention (EN1717)
EB
Connection size
G3/4
DN-size (nominal dimension)
DN20
Hot water supply
max. +70°C
Material
Brass
Working pressure
0.5 - 10 bar
Regulations
EN standard
EN 817
