Main features
for front wall or stud wall mounting
steel frame
with quick adjustment and height lock
Fixing material
2 WC retaining bolts
Ceramic fixing
Screw spacing 180/230 mm
Drainage elbow Ø 90 mm
depth adjustable
Reducer Ø 90/110 mm
Inlet and outlet fitting
Cistern GD 2, 6 - 9 l with the following functions:
factory setting 6l and 3l
pneumatic drain valve with two functions: 2 quantities or start & stop
water connection from left/right/rear or above
Fitting group I
condensation water insulated
Water connection 1/2" with integrated angle valve and tool-free hose fitting
Inspection shaft with protection against unfinished construction, can be mounted without tools
vertical and horizontal installation
Wall bracket 38 558 00M for pre-wall installation must be ordered separately
Inspection chamber 40 911 000 for small cover plates must be ordered separately
