Product main features
with GROHE Rapido U
1.13 and 1.30 m installation height
for manual actuation or Tectroninfra-red electronic 6 V or 230 V
for on-the-wall installations or studded walls
powder coated steel frame, self-supporting
for dry-cladding, completely pre-assembled
height adjustable fitting connections
quick adjustment, lockable
fixing material
TÜV approved
HT-outlet bend Ø 50 mm
inlet connection and inlet connecting set
fixing bolts M8, with fixing device for the ceramic
water group with stop valve
flow pressure min 0.5 bar
operating pressure max 10 bar
flush aid
functional unit checked ex factory
water supply connections ½" outer thread
connecting box for mains supply 230 V
installation box with gasket
inspection shaft incl. protection during construction phase
including wall brackets 38 558 00M for on-the-wall installation
