Head of water max.
40 mm
Click on an application purpose to search more products
For collecting and draining off rainwater from roofs
For syphonic roof drainage systems
For gutters with a minimum width of 30 cm
For connecting metallic product materials with thicknesses ≤ 4 mm
Click on a characteristic to search more products
Vertical outlet
Straight connector can be reduced directly or extended
Straight connector made of PE-HD, can be shortened
Maintenance-free clamping flange joint
Outlet grating with function disc
Base unit made of CrNi steel 1.4301
Flange gasket made of EPDM
Fastening flange with prevailing torque nuts
DN: 56
Sealing of connection: CrNi steel 1.4301
d, ø: 56 mm
Discharge rate: 1–12 l/s
