Battery type Alkaline (1.5 V AA) Protection degree IPX4 Operating voltage 3 V DC Operating pressure 0.5–10 bar Recommended operating pressure with thermostatic mixer 0.5–5 bar Recommended operating pressure with thermostatic mixer 50–500 kPa Differentiated pressure CW/WW max. 1.5 bar Test pressure, water max. 16 bar Test pressure, air / inert gas max. 3 bar Ambient temperature 1–40 °C Storage temperature -20 – +70 °C Water temperature, adjustment range with thermostatic mixer 20–42 °C Operating temperature, water max. 60 °C Operating temperature, water, short-term max. 90 °C Flow rate at 3 bar 5 l/min Minimum flow pressure 0.5 bar Calculated flow rate 0.07 l/s Interval flush, adjustment range 1–168 h Interval flush, factory setting 24 h Interval flush time, adjustment range 5–200 s Interval flush time, factory setting 5 s Product material Brass / plastic Click on an application purpose to search more products For extracting tap water For public and semipublic areas For installation in washbasins or washtops For connecting cold and hot water (only for model with mixer or thermostatic mixer) For connecting cold or mixed water (only for model without mixer) For use with stainless steel bowls Model without mixer suitable for combination with continuous flow heater, see technical data sheet "Washbasin taps with continuous flow heaters" Click on a characteristic to search more products Automatic flush actuation Infrared user detection Self-adjusting IR sensor Vandal-resistant Volume flow control via tap aerator Temperature presetting via mixer (only for models with mixer or thermostatic mixer) Not possible to set just hot water or just cold water (only for model with mixer or thermostatic mixer) Thermostat according to EN 1111 (only for model with thermostatic mixer) Scald protection by limiting the water temperature to 42 °C (only for models with thermostatic mixer) Thermal disinfection according to DVGW W 551 possible Power supply by battery Battery sufficient to activate the water flow 200000 times Warning when the battery is low Economy mode can be set Water saving due to quick-response two-beam scanning technology Functions can be set and queried with the Geberit Service Handy Device settings and operation with mobile device via integrated Bluetooth® interface Compatible with Geberit Control App Wired networkable with Geberit gateway via GEBUS converter Wirelessly connectable with Geberit Gateway via Bluetooth® Compatible with Geberit Connect Water saver program can be set Interval flush program can be set Continuous flush can be set individually Flush actuation can be deactivated With integrated check valve Functional unit with built-in basket filters Washbasin tap with IR sensor and connection hose Exposed function box with control electronics, functional unit and battery compartment Reinforced braided hoses 3/8" Tap aerator key Fastening material Colour / surface: stainless steel finish / brushed, easy-to-clean coated Mixer: without mixer B: 5.5 cm H: 19.3 cm T: 16.7 cm
