Line noise at 3 bar
15 dB(A)
Noise class
1
Inlet capacity at 3 bar
0.35 l/s
Overflow capacity
0.6 l/s
Seal water height (mm)
50 mm
Click on an application to search for other products
For bathtubs with valve hole ø 52 mm
For steel, plastic or cast iron bathtubs
For special size baths
Click on a property to search for other products
Quality-controlled in accordance with EN 274-3
With overflow and inlet
Overflow head can be fixed in an orientated position
Double-sided seals on drain and overflow
Adjustable inlet jet
Pre-assembly set
90° connection angle with MasterFix, 1/2", radial sealing
Connection elbow made of PE-HD, ø 40 / 50 mm
Drain valve
Odour trap
Building protection
Fixing material
Colour / surface: high-gloss chrome-plated
DN: 40
d, ø: 40 / 50 mm
Drainage capacity: 0.85 l/s
PU1: 1 pc.
PU2: 12 pcs.
PU3: 48 pcs.
